Industrial IoT Gateway – unlocking the full potential of your mobility assets
The PTlinks of industrial IoT gateways are engineered to satisfy the toughest environmental and operational requirements, including extreme ambient temperatures, mechanical shock & vibration, humidity, chemical exposure, and stringent IP69K ingress protection. Each gateway is fully integrated and optimized to deliver a cost-effective solution without sacrificing performance, reliability, or long-term durability.
The PTlink AM4-TL offers comprehensive support for industrial communication protocols - such as CAN, LIN, and RS-232 - for seamless vehicle and equipment integration. It also features robust wireless connectivity, including LTE CAT-M1, WLAN/WPA2, and Bluetooth Low Energy (BLE).
All PTlink gateways are supported by a complete Board Support Package (BSP) with flexible APIs, enabling developers to easily build application software and unlock the full range of end-customer functionality.
-
Unlock valuable asset data
Seamless connectivity to capture, process, and leverage critical asset insights for smarter operations.
-
IP69K and Automotive-grade quality
Ruggedized design ensuring maximum durability and reliability under extreme environmental conditions.
-
Cost-optimized design
Efficient architecture delivering high performance at a competitive cost for scalable deployments.
-
Industrial protocols
Comprehensive support for leading industrial communication standards to enable interoperability.
-
Comprehensive BSP
Fully integrated Board Support Package (BSP) for rapid development and streamlined system integration.
Features
- 32-bit Single Core 200 MHz Microcontroller
- 2MB Program Flash
- 520kB SRAM Memory
- 4GB eMMC Storage
- CAN 2.0 up to 1Mbit/s
- LIN 2.1
- I/O: 10A high-side switched output
- Serial: RS-232 receiver
- Mobile connectivity incl. LTE CAT-M1, NB-IoT/GPRS
- Local connectivity incl. WLAN 2.4GHz, with WPA2 (Enterprise) and BLE
Benefits
-
Cost-effective automotive grade IoT gateway
Fully integrated IP69K design for harsh operating environments including automotive & mobility
-
Chemical resistance
Including oil, diesel, antifreeze, brake fluid and battery acid
-
Ready for the S/W application layer
Provided with comprehensive BSP, support for FreeRTOS and Prodrive Technologies File System
-
Regulatory compliance
Fully certified and compliant for RED and FCC. Country Approvals on request
Application areas
Our solutions are engineered to deliver meaningful operational insights from assets across a wide range of industries, including mobility, logistics, maritime, and agriculture.
-
Intralogistics & warehousing
![[Edit] Material handling.jpg](/media/fsanja5e/edit-material-handling.jpg?width=600&v=1dcd232cd92f3f0)
-
Autonomous Moving Robots (AMR)
-
Utility Vehicles
![[Edit] Utility Vehicles.jpg](/media/pbghbbhq/edit-utility-vehicles.jpg?width=600&v=1dcd232ce7564b0)
-
Fleet management
![[Edit] Commercial Vehicles.jpg](/media/rozn5u3n/edit-commercial-vehicles.jpg?width=600&v=1dcd232d0900750)
Markets & industries
-
Industrial
Integration into advanced machines requiring synchronized sensor data, multi‑camera capture, and deterministic FPGA‑based processing
-
Agriculture
Smart connectivity solutions for precision farming, equipment tracking, and environmental monitoring to boost productivity.
-
Marine
Rugged IoT gateways designed for harsh marine environments, supporting vessel telemetry, navigation, and safety systems.
Technical specification
PTlink product catalogue
Let’s find the right fit!
Whether you’re ready to order or need a solution built around your requirements, we’re here to help you move forward
